RMAN Incremental & Demo Part 1 (Level 0)

This blog post is part of the “RMAN Back to Basics” series, which can be found here.

Incremental Backup

An incremental backup only backup up those data blocks that have changed since the last backup.

Types of Incremental Backups

There are 2 types of Incremental Backups:

  1. Level 0 are a base for subsequent backups.  Copies all blocks containing data similar to a full backup, with the only difference that full backups are never included in an incremental strategy.  Level 0 can be backup sets or image copies.
  2. Level 1 are subsequent backups of a level 0, backing up by default all blocks changed after the most recent level 0 or 1, known as differential incremental backup.  More on different types of level 1 backups is discuss in detail here.

Incremental Level 0 Demo

We take an incremental level 0 backup using my script 5_incremental_level_0.sh:

[oracle@dc1sbxdb001 demo]$ ./5_incremental_level_0.sh
-----------------------
Step 1: Set environment
-----------------------

Setting the Database Environment using oraenv...
The Oracle base remains unchanged with value /u01/app/oracle

ORACLE_SID: ZEDDBA
ORACLE_HOME: /u01/app/oracle/product/12.2.0/dbhome_1

Press Enter to continue

The environment is set to my ZEDDBA database, then next the incremental backup (Level 0) is taken:

---------------------------------------
Step 2: Take Incremental Level 0 Backup
---------------------------------------

Cotent of 5_incremental_level_0.cmd file:

BACKUP INCREMENTAL LEVEL 0 DATABASE TAG 'INCR LEVEL 0';
HOST 'read Press Enter to LIST BACKUP';
LIST BACKUP;

Press Enter to continue

Calling 'rman target / cmdfile=/media/sf_Software/scripts/demo/5_incremental_level_0.cmd'

Recovery Manager: Release 12.2.0.1.0 - Production on Mon May 20 17:13:13 2019

Copyright (c) 1982, 2017, Oracle and/or its affiliates. All rights reserved.

connected to target database: ZEDDBA (DBID=3520942925)

RMAN> BACKUP INCREMENTAL LEVEL 0 DATABASE TAG 'INCR LEVEL 0';
2> HOST 'read Press Enter to LIST BACKUP';
3> LIST BACKUP;
4>
Starting backup at 20-MAY-19
using target database control file instead of recovery catalog
allocated channel: ORA_DISK_1
channel ORA_DISK_1: SID=15 device type=DISK
channel ORA_DISK_1: starting incremental level 0 datafile backup set
channel ORA_DISK_1: specifying datafile(s) in backup set
input datafile file number=00001 name=/u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_system_gftkr3fv_.dbf
input datafile file number=00002 name=/u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_sysaux_gftkr792_.dbf
input datafile file number=00003 name=/u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_undotbs1_gftkr944_.dbf
input datafile file number=00004 name=/u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_users_gftkr9fc_.dbf
channel ORA_DISK_1: starting piece 1 at 20-MAY-19
channel ORA_DISK_1: finished piece 1 at 20-MAY-19
piece handle=/u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_20/o1_mf_nnnd0_INCR_LEVEL_0_gg5njx01_.bkp tag=INCR LEVEL 0 comment=NONE
channel ORA_DISK_1: backup set complete, elapsed time: 00:00:07
Finished backup at 20-MAY-19

Starting Control File and SPFILE Autobackup at 20-MAY-19
piece handle=/u01/app/oracle/fast_recovery_area/ZEDDBA/autobackup/2019_05_20/o1_mf_s_1008782004_gg5nk4cs_.bkp comment=NONE
Finished Control File and SPFILE Autobackup at 20-MAY-19


host command complete

We use host within RMAN just to wait for input before moving on for demo purposes.  Next we list the backup within RMAN using ‘LIST BACKUP‘:

List of Backup Sets
===================

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
1 Full 498.93M DISK 00:00:08 16-MAY-19
BP Key: 1 Status: AVAILABLE Compressed: NO Tag: FULL BACKUP
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_16/o1_mf_nnndf_FULL_BACKUP_gfv4k119_.bkp
List of Datafiles in backup set 1
File LV Type Ckp SCN Ckp Time Abs Fuz SCN Sparse Name
---- -- ---- ---------- --------- ----------- ------ ----
1 Full 353825 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_system_gftkr3fv_.dbf
2 Full 353825 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_sysaux_gftkr792_.dbf
3 Full 353825 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_undotbs1_gftkr944_.dbf
4 Full 353825 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_users_gftkr9fc_.dbf

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
2 Full 8.31M DISK 00:00:00 16-MAY-19
BP Key: 2 Status: AVAILABLE Compressed: NO Tag: TAG20190516T173912
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/autobackup/2019_05_16/o1_mf_s_1008437952_gfv4kjko_.bkp
SPFILE Included: Modification time: 16-MAY-19
SPFILE db_unique_name: ZEDDBA
Control File Included: Ckp SCN: 353836 Ckp time: 16-MAY-19

BS Key Size Device Type Elapsed Time Completion Time
------- ---------- ----------- ------------ ---------------
3 77.83M DISK 00:00:01 16-MAY-19
BP Key: 3 Status: AVAILABLE Compressed: NO Tag: FULL BACKUP PLUS ARCHIVELOG
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_16/o1_mf_annnn_FULL_BACKUP_PLUS_ARC_gfv4y7m2_.bkp

List of Archived Logs in backup set 3
Thrd Seq Low SCN Low Time Next SCN Next Time
---- ------- ---------- --------- ---------- ---------
1 13 332298 16-MAY-19 354044 16-MAY-19

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
4 Full 498.94M DISK 00:00:06 16-MAY-19
BP Key: 4 Status: AVAILABLE Compressed: NO Tag: TAG20190516T174603
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_16/o1_mf_nnndf_TAG20190516T174603_gfv4yco3_.bkp
List of Datafiles in backup set 4
File LV Type Ckp SCN Ckp Time Abs Fuz SCN Sparse Name
---- -- ---- ---------- --------- ----------- ------ ----
1 Full 354058 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_system_gftkr3fv_.dbf
2 Full 354058 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_sysaux_gftkr792_.dbf
3 Full 354058 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_undotbs1_gftkr944_.dbf
4 Full 354058 16-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_users_gftkr9fc_.dbf

BS Key Size Device Type Elapsed Time Completion Time
------- ---------- ----------- ------------ ---------------
5 3.50K DISK 00:00:00 16-MAY-19
BP Key: 5 Status: AVAILABLE Compressed: NO Tag: FULL BACKUP PLUS ARCHIVELOG
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_16/o1_mf_annnn_FULL_BACKUP_PLUS_ARC_gfv4ym4v_.bkp

List of Archived Logs in backup set 5
Thrd Seq Low SCN Low Time Next SCN Next Time
---- ------- ---------- --------- ---------- ---------
1 14 354044 16-MAY-19 354066 16-MAY-19

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
6 Full 8.31M DISK 00:00:00 16-MAY-19
BP Key: 6 Status: AVAILABLE Compressed: NO Tag: TAG20190516T174612
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/autobackup/2019_05_16/o1_mf_s_1008438372_gfv4ynmv_.bkp
SPFILE Included: Modification time: 16-MAY-19
SPFILE db_unique_name: ZEDDBA
Control File Included: Ckp SCN: 354077 Ckp time: 16-MAY-19

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
7 Full 8.31M DISK 00:00:00 17-MAY-19
BP Key: 7 Status: AVAILABLE Compressed: NO Tag: TAG20190517T165453
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/autobackup/2019_05_17/o1_mf_s_1008521693_gfxpbfs7_.bkp
SPFILE Included: Modification time: 17-MAY-19
SPFILE db_unique_name: ZEDDBA
Control File Included: Ckp SCN: 458035 Ckp time: 17-MAY-19

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
8 Incr 0 511.64M DISK 00:00:05 20-MAY-19
BP Key: 8 Status: AVAILABLE Compressed: NO Tag: INCR LEVEL 0
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/backupset/2019_05_20/o1_mf_nnnd0_INCR_LEVEL_0_gg5njx01_.bkp
List of Datafiles in backup set 8
File LV Type Ckp SCN Ckp Time Abs Fuz SCN Sparse Name
---- -- ---- ---------- --------- ----------- ------ ----
1 0 Incr 571045 20-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_system_gftkr3fv_.dbf
2 0 Incr 571045 20-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_sysaux_gftkr792_.dbf
3 0 Incr 571045 20-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_undotbs1_gftkr944_.dbf
4 0 Incr 571045 20-MAY-19 NO /u01/app/oracle/oradata/ZEDDBA/datafile/o1_mf_users_gftkr9fc_.dbf

BS Key Type LV Size Device Type Elapsed Time Completion Time
------- ---- -- ---------- ----------- ------------ ---------------
9 Full 8.31M DISK 00:00:00 20-MAY-19
BP Key: 9 Status: AVAILABLE Compressed: NO Tag: TAG20190520T171324
Piece Name: /u01/app/oracle/fast_recovery_area/ZEDDBA/autobackup/2019_05_20/o1_mf_s_1008782004_gg5nk4cs_.bkp
SPFILE Included: Modification time: 20-MAY-19
SPFILE db_unique_name: ZEDDBA
Control File Included: Ckp SCN: 571056 Ckp time: 20-MAY-19

Recovery Manager complete.

Press Enter to continue

Finally, we update the demo log table:

-------------------------------------
Step 3: Updating and viewing demo log
-------------------------------------
Calling 'sqlplus / as sysdba'
To updated and view demo log

1 row created.

Commit complete.

WHEN COMMENTS
------------------------------ --------------------------------------------------
16-MAY-19 05.31.24.000000 PM Enable Archive Log Mode
16-MAY-19 05.40.23.000000 PM Full Backup
16-MAY-19 05.46.17.000000 PM Full Backup plus Archive Logs
17-MAY-19 04.55.12.000000 PM Image Copy
20-MAY-19 05.13.44.000000 PM Incremental Level 0

Press Enter to exit shell script

[oracle@dc1sbxdb001 demo]$

Reference

Scripts

  1. 5_incremental_level_0.sh
  2. 5_incremental_level_0.cmd

To download all 2 in one zip: 5_incremental_level_0.zip

The rest of the series

  1. Oracle Database File Placement Best Practice & Create Database Demo
  2. RMAN Full Backup & Demo
  3. RMAN Image Copy & Demo
  4. RMAN Incremental & Demo Part 1 (Level 0)
  5. RMAN Incremental & Demo Part 2 (Level 1)
  6. RMAN Incremental with Block Change Tracking & Demo
  7. RMAN Incremental Differential vs Cumulative & Demo
  8. RMAN Incremental Updating Backup & Demo Part 1
  9. RMAN Incremental Updating Backup & Demo Part 2
  10. Flashback
  11. RMAN Block Media Recovery
  12. RMAN Recover database with only FRA
  13. RMAN Obsolete

Please Note: Links to the blog posts will be released daily and updated here.



If you found this blog post useful, please like as well as follow me through my various Social Media avenues available on the sidebar and/or subscribe to this oracle blog via WordPress/e-mail.

Thanks

Zed DBA (Zahid Anwar)
